Cnc Vertical Lathe Ck5126
Tool rest adopts the T-type ram manual 5-tool position tool table structure with good rigidity and convenient tool change. Worktable is manual 4-jaw single movement chuck.
Description
Cnc Vertical Lathe Ck5126
Vertical Chinese metal lathe is suitable to process ferrous metal, nonferrous metals and partial non-metallic material, and could achieve the processing of turning of the end face, inside and outside cylindrical surface, inside and outside circular conical surface and drilling, expanding, reaming of the hole. The vertical lathe machine cutting action is controlled by the PLC, and feeding axis is driven by the AC asynchronous servo motor, with touch screen display and hand-held pulsed. Main transmission is driven by the spindle AC servo motor, hydraulic gear change and two gears stepless speed regulation.
| Specification | Units | CK5110 | CK5112 | CK5116 | CK5120 | CK5123 | CK5126 | CK5132 |
|---|---|---|---|---|---|---|---|---|
| Table diameter | mm | 900 | 1000 | 1400 | 1800 | 2000 | 2300 | 2830 |
| Max.turning diameter | mm | 1000 | 1250 | 1600 | 2000 | 2300 | 2600 | 3200 |
| Max.height of workpiece | mm | 800 | 1000 | 1200/1400 | 1250 | 1350/1600 | 1500/1800 | 1500/1800 |
| Max.weight of workpiece | T | 2 | 3.5 | 5 | 8 | 8 | 10 | 12 |
| Table speed range | rpm | 8-250 | 6.2-200 | 5-160 | 3.2-100 | 3.2-100 | 2.5-80 | 2-63 |
| Table speed steps | 18 | 18 | 22 | 22 | 22 | 22 | 22 | |
| Max.torque of table | N·m | 20000 | 25000 | 30000 | 40000 | 40000 | 45000 | 45000 |
| Vertical tool post feed range | mm/min | 0-500 | 0-500 | 0-500 | 0-500 | 0-500 | 0-500 | 0-500 |
| Vertical tool post feed steps | steps | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Max.Cutting force of vertical tool post | KN | 18 | 18 | 22 | 22 | 22 | 22 | 22 |
| Max.travel of vertical tool post(horizontal) | mm | 670 | 700 | 915 | 1050 | 1180 | 1600 | 1800 |
| Max.travel of vertical tool post(verticall) | mm | 650 | 650 | 800 | 800 | 1000 | 1000 | 1000 |
| Swivel angle of vertical tool post | ° | ±30 | ±30 | ±30 | ±30 | ±30 | ±30 | ±30 |
| Max.Cutting force of side tool post | N | 23000 | 23000 | 23000 | 23000 | 23000 | 23000 | 23000 |
| Side tool post travel(horizontal) | mm | 630 | 630 | 630 | 630 | 630 | 630 | 630 |
| Side tool post travel(vertical) | mm | 900 | 900 | 900 | 900 | 900 | 900 | 900 |
| Tool post rapid traverse | mm/min | 2300 | 2300 | 2300 | 2300 | 2300 | 2300 | 2300 |
| Tool size | mm | 30*40 | 30*40 | 30*40 | 30*40 | 30*40 | 30*40 | 30*40 |
| Max.travel of cross beam | mm | 650 | 650 | 800 | 800 | 1000 | 1000 | 1000 |
| Cross beam lifting speed | mm/min | 440 | 440 | 440 | 440 | 440 | 440 | 440 |
| Cross beam lifting motor power | kw | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 |
| Main motor power | kw | 18.5 | 22 | 22/30 | 30 | 30 | 37 | 45 |
| Machine weight | kg | 8500 | 9000 | 12000 | 175000 | 185000 | 21000 | 26000 |
| Overall dimension | mm | 2187*22002760 | 2360*2270*2800 | 2830*2670* 3010/3210 | 3200*2800*3250 | 3210*2850*3300/3500 | 3300*4000* 3500/3800 | 3300*4000* 3500/3800 |
